时钟和数据恢复:超低功耗,非凡性能
Semtech 的超低功耗、高性能、无参考时钟和数据恢复 (CDR) 产品系列以我们的 ClearEdge® CDR 以及 Tri-Edge™ CDR 为基础,分别适用于 10Gbps、16Gbps 和 100Gbps 的 NRZ(非归零)应用,以及 200Gbps 和 400Gbps 的 PAM4 应用。我们的 ClearEdge 和 Tri-Edge 产品基于无参考 CDR 架构,提供具有最佳灵敏度、输出抖动和抖动容限的多通道信号调节器,还可与激光驱动器和跨阻放大器 (TIA) 单片集成以提供紧凑的高性能解决方案。
用于 NRZ 信号处理的 ClearEdge® CDR 平台
Semtech 的 ClearEdge CDR 为光模块提供最低功率、最小封装的解决方案,包括:
- QSFP28
- CFP4
- XFP
- 重定时 SFP+
- 其他 25G 和 100G 模块以及有源光缆 (AOC)
Semtech 的 ClearEdge CDR 是世界上选用最广泛的光收发器 CDR,可用于 10G 和 100G 数据中心应用。
用于 PAM4 信号处理的 Tri-Edge™ CDR 平台
Semtech 基于 ClearEdge NRZ 的 CDR 平台技术大获成功,在此基础上打造的 Tri-Edge 是针对 PAM4 光互连而优化的 CDR 平台,适用于下一代 200G 和 400G 数据中心模块以及 AOC 应用。SR Tri-Edge PAM4 CDR 芯片组可为长达 100 米的多模光纤链路提供业界领先的功率和更低的延迟和成本。Tri-Edge 长距离平台可实现长达 10 千米的 200G 和 400G 单模光纤解决方案。Tri-Edge 短距离和长距离产品系列均与 Open Eye MSA 的短距离和长距离链路规范兼容。
Semtech 引领着数据中心市场实现基于模拟 PAM4 的解决方案,并通过 Open Eye MSA 打造了一个完整的模拟 PAM4 生态系统。
Semtech 的 Tri-Edge PAM4 CDR 为光模块提供最低功率、最低成本的解决方案,包括:
- DSFP
- QSFP56
- QSFP-DD
- OSFP
- SFP56
- SFP-DD
- 50G AOC
- 100G AOCs
- 200G AOC
- 400G AOC
