概览
该开发套件配备有 Semtech 的 LoRa Edge™ LR1120,并针对欧洲的 LoRa 868MHz 工业、科学和医疗 (ISM) 频段以及全球 2.4GHz ISM 频段进行了配置。
功能
- 基于 LR1120
- PCB 层:4
- 32MHz 参考时钟:TCXO
- 地区: 欧洲
- 频段:868MHz 和 2.4GHz
- 输出功率:14dBm (Sub-GHz) 和 11.5dBm (2.4GHz)
- 每个开发套件都包含两个不同的射频模块:
- PCB 版本编号:E655V01A
- 用于无源 GNSS 天线的单射频 (RF) 模块产品编号:LR1120MB1DIS
- PCB 版本编号:E656V01A
- 用于有源 GNSS 天线的单射频 (RF) 模块产品编号:LR1120MB1DJS
- PCB 版本编号:E655V01A
文档 | Release Date | Type | |
---|---|---|---|
LR1120 参考设计介绍 | 2022-10-24 | ||
LR1120DVK1TBKS 套件 @868MHz 的设计文件 | 2023-06-26 | ZIP | |
ETSI Test Report for LR1120 Development Kit | 2022-12-15 | ZIP |
