概览
Transient diverting suppressors (TDS), part of the SurgeSwitch portfolio, are designed to provide protection against electrical overstress events (EOS). These devices have superior clamping and stability over temperature when compared to standard transient voltage suppressor (TVS) devices. The device uses a surge rated FET as the main protection element. A precisely tuned trigger circuit activates the shunt FET when an EOS event is detected. The TDS clamping voltage is nearly constant across the rated peak pulse current range due to the extremely low ON Resistance of the FET.
功能
- 瞬态保护：
- IEC 61000-4-2 (ESD) ±30kV (air), ±30kV (contact)
- IEC 61000-4-4 (EFT) ±4kV (100kHz & 5kHz, 5/50ns)
- IEC 61000-4-5（浪涌）40A (8/20µs)
- IEC 61000-4-5 (Surge) ±2kV (1.2x50µs)
- 额定峰值脉冲电流范围和温度范围内几乎恒定的钳位电压
- 保护一条 I/O 或电源线路
- Working voltage: 14V
- Solid-state technology
| 文档 | Release Date | Type |  |
|---|---|---|---|
| TDS1411P Datasheet | 2023-12-05 | |
应用
- 12V power line protection
- Panels and displays
- Industrial equipment
- Solid-state drives
- 远程仪表
- 物联网 (IoT) 器件
