概览
RailClamp® TVS 二极管专为保护连接到高速数据和传输线的敏感元件而设计，以防止 ESD（静电放电）、CDE（电缆放电事件）和 EFT（电气快速瞬变）导致的过电压。
功能
- 高速数据线路 ESD 防护符合以下标准
- IEC 61000-4-2 (ESD) ±30kV (air), ±30kV (contact)
- IEC 61000-4-4 (EFT) 40A (5/50ns)
- IEC 61000-4-5 (Lightning) 25A (8/20μs)
- Array of surge rated diodes with internal TVS Diode
- Small package saves board space
- Protects four I/O lines and Voltage Bus
- Low capacitance: 5pF (VR=0V)
- 钳位电压低
- Low operating voltage: 5.0V
- 固态硅雪崩技术
| 文档 | Release Date | Type |  |
|---|---|---|---|
| RCLAMP0534N Datasheet | 2018-12-15 | | |
应用
- USB 2.0 Power and Data Line Protection
- 显卡
- Monitors and Flat Panel Displays
- Digital Video Interface (DVI)
- Notebook Computers
- Networking Equipment
