概览
RailClamp® TVS diode arrays are specifically designed to protect sensitive components which are connected to high-speed data and transmission lines from overvoltage caused by ESD (electrostatic discharge), CDE (Cable Discharge Events), and EFT (electrical fast transients).
封装
- USB 3.0
- HDMI 1.4
- uSD Card Interfaces
- MMC Card Interfaces
- MDDI / mipi Interfaces
订购代码
- RClamp0506T.TCT
PB Free/ROHS
Learn More →功能
- Transient protection for high-speed data lines to
- IEC 61000-4-2 (ESD) ±15kV（空气），±8kV（接触）
- IEC 61000-4-4 (EFT) 40A (5/50ns)
- Array of surge rated diodes with internal TVS Diode
- Small package saves board space
- Protects up to 6-Lines operating at 5V
- Low capacitance (<0.8pF)
- No insertion loss to 2.0GHz
- 小漏电流
- 钳位电压低
- Innovative package for easy pcb layout
- 固态硅雪崩技术
| 文档 | Release Date | Type |  |
|---|---|---|---|
| RCLAMP0506T Datasheet | 2018-12-15 | | |
应用
- Transient protection for high-speed data lines to
- IEC 61000-4-2 (ESD) ±15kV（空气），±8kV（接触）
- IEC 61000-4-4 (EFT) 40A (5/50ns)
- Array of surge rated diodes with internal TVS Diode
- Small package saves board space
- Protects up to 6-Lines operating at 5V
- Low capacitance (<0.8pF)
- No insertion loss to 2.0GHz
- 小漏电流
- 钳位电压低
- Innovative package for easy pcb layout
- 固态硅雪崩技术
Inventory
| Product | 国家/地区 | 经销商 | Qty | Buy |
|---|
