uClamp0701ZV
The μClamp0701ZV is a unidirectional TVS specifically designed for single power line protection up to +7.3V. It features large cross-sectional area junctions for conducting high transient currents while occupying minimal board space in a slim 1006(mm) package. Desirable characteristics for board level protection include fast response time, low operating and clamping voltage, and no device degradation.
功能
- 高 ESD 耐受电压：符合 IEC 61000-4-2 标准，±30kV（接触）和 ±30kV（空气）
- High peak pulse current capability: 25A (tp = 8/20μs)
- Small package (1.0 x 0.6 x 0.25mm)
- 保护一条线路
- 低 ESD 钳位电压
- Working voltage: +7.3V
- 蜂窝手机和配件
- 电池保护
- 笔记本电脑和手持设备
- USB 总线电压
应用
封装
- DFN 1.0x0.60x0.25mm-2 Lead
订购代码
- μClamp0701ZVTFT
Pb(Lead)-Free/RoHS-Green Info
