概览
uClamp® series are designed to protect sensitive electronics from damage or latch-up due to electrostatic discharge (ESD). They feature large cross-sectional area junctions for conducting high transient currents. They offer desirable characteristics for board level protection including fast response time, low operating and clamping voltage and no device degradation.
功能
- High ESD withstand voltage: ±30kV (Contact) and ±30kV (Air) per IEC 61000-4-2
- High peak pulse current capability: 50A (tp = 8/20μs)
- 保护一条 I/O 或电源线路
- Qualified to AEC-Q100 (Grade 1) and AEC-Q101
- 低 ESD 钳位电压
- Working voltage: ±3.3V
- 固态硅雪崩技术
| 文档 | Release Date | Type |  |
|---|---|---|---|
| UCLAMP03321PQ Datasheet | 2024-04-20 | | |
应用
- 汽车应用
- Cellular handsets and accessories
- Battery protection
- Notebooks and handhelds
- USB voltage bus
- Audio lines
