Semtech TClamp2472S 24V, High-Surge Transient Protection Array Provides Industry-leading Protection for xDSL Data Interfaces, Industrial and Communications Infrastructure Systems
The TClamp2472S expands Semtech’s TransClamp® platform; enhances system robustness and guards circuits from destructive overvoltage transient threats
Camarillo, California - August 9, 2016 -
Semtech Corporation (Nasdaq: SMTC), a leading supplier of analog and mixed-signal semiconductors, today announced the TClamp2472S, a versatile two-line, low-capacitance transient protection array designed to safeguard xDSL interfaces from dangerous transient voltage threats. In addition to xDSL interfaces, it is also appropriate for safeguarding broad-based data links serving industrial and communications infrastructure.
The TClamp2472S offers 20A (8x20µs waveform) of surge immunity in an industry-standard SOT-23 package. The dual-line device delivers industry-leading transient protection while also presenting a minimal line-to-line capacitance of less than 3.5pF. Robust (20A, tp=8/20μs) surge rating for high-surge lightning protection helps xDSL equipment makers achieve compliance with the industry’s stringent EMC immunity requirements.
The TClamp2472S represents Semtech’s latest addition to the highly-differentiated TransClamp® platform, which offers high-surge immunity with ultra-small junction capacitance. The high-surge, low capacitance advantages are enabled by Semtech’s industry-leading process technology, which achieves extremely low clamping voltage with significant reductions in leakage current and capacitance.
“Higher speed implementations of xDSL continue to proliferate in emerging broadband markets. Low capacitance, efficient clamping transient voltage suppressor TVS devices are increasingly essential for protecting these data circuits,” said Rick Hansen, Product Marketing Director for Semtech’s Protection Products Group. “The TClamp2472S offers substantial performance advantages for safeguarding links from the frequent ESD and surge strikes common to these ports.”
Key Features of the TClamp2472S
- Transient protection for high-speed data lines to: IEC 61000-4-2 (ESD) ±8kV (contact); IEC 61000-4-4 (EFT) 40A (5/50ns); IEC 61000-4-5 (Lightning) 20A (8/20μs)
- 24V working voltage protection
- High surge capability: 20A (tp=8/20μs)
- Protects two I/O lines (1differential pair)
- Low capacitance (<3.5 pF line-to-line)
- Industry Standard SOT-23 package
- AEC-Q100 qualified device
- Pb Free and RoHS/WEEE compliant
Pricing and Availability
The TClamp2472S (order code: TClamp2472S.TCT) is available immediately in production quantities and is priced at $0.28 each in 10,000-piece lots. Semtech offers comprehensive design assistance, including field- and factory-based support. Data sheets, volume pricing, and delivery quotes, as well as evaluation kits and samples, are available by contacting email@example.com.
