Semtech Neo-Iso™ Platform Now Features Next Generation Energy Harvesting Capability
TS13102 and TS13103 solid state relays enable self-powered control systems in Internet of Things applications
Camarillo, California - August 23, 2016 -
Semtech Corporation (Nasdaq: SMTC), a leading supplier of analog and mixed-signal semiconductors, today announced the production release of the TS13102 and TS13103 solid state relays. These enhanced solid state relays expand the company’s Neo-Iso™ product platform and enable self-powered control systems in Internet of Things (IoT) applications, such as smart thermostats, alarm panels, factory automation systems, smart controls and more.
The TS13102 solid state relay can autonomously harvest energy even when its switch is closed and without the assistance of a microcontroller. The harvested energy is stored in a system capacitor (Csys) and can be shared across multiple channels in the system driving several loads simultaneously. The TS13103 is outfitted with a Power Transfer Output pin (PTO) to transfer the harvested energy on the other side of the isolation barrier to the controller of the system. This design allows for much smaller systems that can last decades without needing their batteries replaced. It also eliminates the need to include costly transformers and AC/DC power supplies with the system, which significantly reduces the bill of materials (BOM) cost.
Both TS13102 and TS13103 relays have a new, enhanced communication scheme that allows the controller to send specific commands through the control line (CLK) to perform a variety of functions, including receiving diagnostic information. The control and feedback lines can be shared across multiple channels, greatly reducing the system microcontroller pin count. These latest additions to Semtech’s Neo-Iso product portfolio offer designers the benefit of significant board space savings and BOM cost savings compared to mechanical relays, as well as silent operation, diagnostic capability and a major Increase in the lifetime of the product.
“This is an exciting addition to our next generation Neo-Iso product line,” said Phil Daggett, Senior Marketing Director for Semtech’s Power and High Reliability Product Group. “By eliminating the need for an additional power supply for the microcontroller, the TS13102 and TS13103 solid state relays give designers energy harvesting capability in a space saving package that can be easily integrated into a wide range of IoT applications.”
Key Features of the TS13102 & TS13103
- Energy harvesting from the load with integrated bridge diodes
- Automatic, dithering-enabled energy harvesting while the switch is closed
- Enhanced diagnostic feedback with status, fault information and voltage detection
- Three address pins allowing for up to eight switches on the same control line (CLK)
- Programmable watch dog pin (WD) to safely disconnect the load after CLK lack of activity
- Small 16-pin 3x3 mm QFN package
- TS13102 product page: www.semtech.com/power-management/load-switch-ics/ts13102
- TS13103 product page: www.semtech.com/power-management/load-switch-ics/ts13103
- For technical support or general product inquiries, contact Semtech’s support team.
- For quarterly product updates, sign up for Semtech’s e-newsletter Inside Circuit.
- Find Semtech on Twitter, Facebook, LinkedIn and Google+.
Pricing and Availability
TS13102 and TS13103 (order codes: TS13102-QFNR, TS13103-QFNR) are available immediately in production quantities and either are priced at $0.79 each in 1,000-piece lots. Semtech offers comprehensive design assistance, including field- and factory-based support. Data sheets, volume pricing, and delivery quotes, as well as evaluation kits and samples, are available at www.semtech.com/info.
