Semtech Delivers Industry’s First Solution for Transporting up to Eight HDTV SDI Signals Across a Single 12G SDI Link
Solution featured in Semtech’s 12G link concatenation live demo at IBC 2016
Camarillo, California - September 8, 2016 -
Semtech Corporation (Nasdaq: SMTC), a leading supplier of analog and mixed-signal semiconductors, will demonstrate eight 1.5G serial digital interface (SDI) signals transported across a single 12G SDI coaxial cable link utilizing its GS12070 Gearbox at the International Broadcasting Convention (IBC) exhibition, stand 10.F46, on September 9-13 in Amsterdam.
The ability to transport up to eight 1.5G HDTV SDI signals across a single 12G link adds additional capabilities to facilities with 12G SDI infrastructures by simplifying the routing and distribution of multiple 1.5G HDTV signals. Rather than utilizing up to eight discreet coaxial links, 12G link concatenation exploits the massive bandwidth available in a single 12G link to transport up to eight 1.5G SDI signals.
The 12G concatenated link conforms to The Society of Motion Picture and Television Engineers’ (SMPTE) proposed ST 2082-30 12G SDI link concatenation standard. Link concatenation utilizing SMPTE’s proposed standard can significantly reduce infrastructure complexity and cost without additional risk of interoperability issues in a facility that supports multiple data rates, including 1.5G, 3G, 6G, and 12G SDI.
The demonstration utilizes Semtech’s GS12070 Gearbox. The GS12070 is the industry’s only single chip SDI link concatenation and rate conversion solution that enables equipment manufacturers and broadcasters to take a standards-based, commercial, off-the-shelf approach to UHDTV infrastructures.
“Link concatenation is a necessary requirement for any broadcast facility installing new 12G infrastructures,” said Don Shaver, Director of Video Marketing for Semtech’s Signal Integrity Product Group. “Beyond the inherent efficiency of transporting multiple signals across a single 12G SDI link, the ability to do so while providing seamless interoperability in a fully standards-based environment is a critical requirement for any new facility.”
Key Features of the GS12070
- Link Concatenation: Supports SMPTE’s proposed ST2082-30 12G link concatenation standard facilitating multiple 1.5G, 3G, 6G SDI signals across a single 12G link.
- Fully integrated gearbox solution: Four-input and four-output ASIC supporting conversions between multi-link, dual-link and single-link UHD-SDI interfaces.
- Automatic skew correction: For multi-link inputs, automatic compensation for channel skew—an unavoidable system challenge in multi-link UHD-SDI systems—that exceeds the SMPTE’s recommended skew tolerance specification. This minimizes the need for additional system resources and simplifies the overall system design.
- Integrated 4x4 crosspoint switch: Enables signal routing by selecting from any of the four 12G UHD-SDI inputs to any of the four 12G UHD-SDI outputs making it an ideal choice for UHDTV routing and distribution applications. In addition, any of the active outputs can be copied to unused outputs.
- Automatic link ordering: Automatic link ordering for multi-link interfaces simplifies integration and automatically compensates for UHD-SDI cabling issues that often arise during installation.
- GS12070 Product Page: www.semtech.com/broadcast-video/uhd-sdi-gearbox/gs12070
- UHD-SDI Selector Guide: www.semtech.com/images/mediacenter/collateral/Gennum-Video_Broadcast-Guide.pdf
- Contact Semtech’s support team for technical support or general product inquiries.
- Sign up for Semtech’s e-newsletter Inside Circuit for quarterly product updates.
- Find Semtech on Twitter, Facebook, LinkedIn and Google+.
The GS12070 will be available for sale the second half of 2016. Semtech offers comprehensive design assistance, including field- and factory-based support. Data sheets, volume pricing and delivery quotes, as well as evaluation kits and samples, are available at www.semtech.com/info.
